Commercial & industrial all-in-one liquid/air-cooled ESS cabinet with regional safety isolation, single-cell thermal management, and up to 92% system efficiency.
Standardized modular energy storage with regional safety isolation and proactive multi-level fire prevention, this liquid/air-cooled cabinet reaches up to 98.6% PCS efficiency (92% system) and is insured by PICC, with real-time Web/app monitoring and AI-driven revenue optimization.
Contact Us →
| Cooling Method | Air Cooling / Liquid Cooling Integrated (Customizable) |
|---|---|
| Installation Method | Floor-standing |
| Max System Efficiency | PCS: 98.6% / System: 92% |
| Communicational Interface | CAN / RS485 |
| Ingress Protection Rating | IP54 |
| Operating Temperature Range | -25 ~ +50°C |
| Nominal Charge/Discharge Rate | 0.5P |
| Nominal Charge/Discharge Power (kW) | 125 |
| Cell Chemistry | LFP (LiFePO4) |
|---|---|
| Cell Configuration | XC5×52P |
| Cell Specification | 3.2V / 314Ah |
| Nominal Voltage (V) | 832V DC |
| Grid Nominal Voltage | 400V 3L/N/PE |
| Usable Capacity (kW/kWh) | 125kW / 261kWh |
| Cooling Method | Air Cooling / Liquid Cooling Integrated (Customizable) |
|---|---|
| Installation Method | Floor-standing |
| Max System Efficiency | PCS: 98.6% / System: 92% |
| Communicational Interface | CAN / RS485 |
| Ingress Protection Rating | IP54 |
| Operating Temperature Range | -25 ~ +50°C |
| Nominal Charge/Discharge Rate | 0.5P |
| Nominal Charge/Discharge Power (kW) | 125 |
| Cell Chemistry | LFP (LiFePO4) |
|---|---|
| Cell Configuration | XC5×52P |
| Cell Specification | 3.2V / 628Ah |
| Nominal Voltage (V) | 832V DC |
| Grid Nominal Voltage | 400V 3L/N/PE |
| Usable Capacity (kW/kWh) | 125kW / 522kWh |
